Model No: KG-HY-D400D
Four Way Single Phase Din Rail Meter Box
CANGO manufactures four way din rail meter enclosures with anti-tamper design, outdoor protection, and flexible installation options.
Quantity :
Cango KG-HY-D400D Four Way Single Phase Din Rail Meter Box
Introduction
CANGO supplies this Four Way Din Rail Meter Enclosure for projects requiring multiple meter positions. Designed as a four way din rail meter enclosure, din rail meter enclosure, and outdoor din rail meter box, it offers compact layout, durable insulation, and dependable weather protection.
Key Features
- Four way meter layout
- Anti-tamper design
- Outdoor protection structure
- Suitable for wall mounted or pole mounted installation
- Compact internal layout
- Reliable weather resistance
Products Parameters
| S.N. | PARAMETERS | KG-HY-D100D | KG-HY-D200D | KG-HY-D400D |
|---|---|---|---|---|
| 1 | Meter Type | Din Rail Meter | Din Rail Meter | Din Rail Meter |
| 2 | Meter Ways | 1 Way | 2 Way | 4 Way |
| 3 | Dimensions (HxWxD, mm) | 265*220*130 | 365*180*130 | 365x270x128 |
| 4 | Maximum operating temperature | 85℃ | ||
| 5 | Maximum relative humidity | 100% | ||
| 6 | Maximum annual rainfall | 2000 mm | ||
| 7 | Maximum altitude above mean sea level | 3000m | ||
| 8 | Water Absorption | ≤ 0.1% | ||
| 9 | protection level | IP54 | ||
| 10 | Resistance to mechanical shocks | IK09 | ||
| 11 | Flammability | UL94-V0 | ||
| 12 | Mechanical strength | Strength:64MPA Flexural strength:103MPA | ||
| 13 | Light transmission (Transparent window) | >88% | ||
| 14 | Heat Deflection | ≥158℃ | ||
| 15 | Heat resistant & Flame retardant (Glow Wire) | ≥750℃ & ≥960℃ | ||
| 16 | Installation type | Wall mounted / Pole mounted | ||
| 17 | Installation Location | Indoor / Outdoor | ||
Product Advantages
This Four Way Din Rail Meter Enclosure is designed for projects that require multiple metering positions in a compact structure. With anti-tamper design and reliable weather resistance, it helps improve protection and installation efficiency.
Application Scenarios
- Outdoor metering projects
- Utility distribution systems
- Residential electrical installations
- Pole-mounted meter protection
- Infrastructure applications
OEM / ODM Customization
CANGO supports OEM and ODM service for this product. We can customize structure, material, color, logo, packaging, lock design, and internal accessory configuration according to project requirements.
Packaging & Delivery
Standard export packing is available for this meter box. Samples can be arranged for testing and confirmation. Please contact us for lead time, packaging details, and shipping solutions.
Installation Method
This model can be installed by wall mounting or pole mounting depending on site requirements. Optional brackets and accessories can be provided for different installation conditions.
FAQ
Q: Is this designed for four meter positions?
A: Yes, it is a four way meter enclosure.
A: Yes, it is a four way meter enclosure.
Q: Can it be used outdoors?
A: Yes, it is designed for outdoor metering applications.
A: Yes, it is designed for outdoor metering applications.
Q: Does it support sealing?
A: Yes, sealing and anti-tamper options are available.
A: Yes, sealing and anti-tamper options are available.
Q: Can it be wall mounted or pole mounted?
A: Yes, wall mounting and pole mounting are available depending on the project requirement.
A: Yes, wall mounting and pole mounting are available depending on the project requirement.
Q: Do you support OEM and ODM service?
A: Yes, we support OEM and ODM service for structure, color, logo, packaging, and accessories.
A: Yes, we support OEM and ODM service for structure, color, logo, packaging, and accessories.
Q: Can I request a sample before bulk order?
A: Yes, samples can be arranged for testing and approval before mass production.
A: Yes, samples can be arranged for testing and approval before mass production.
